As the industry heads towards a compliant, traceable, and evidence-based future, there has never been a better need to understand anchor/fixing compliance.

A current hurdle within the M&E sector is the last-minute approach. In a time-strapped environment, it is not often recognised how important installer and supervisor training is. As a solutions provider to the M&E sector we recommend early engagement as soon as the tier 1 contractor has tendered the M&E contract.

If the importance of anchors/fixings is discussed at this stage, it is highly likely that training requirements can be identified before any anchors/fixings are installed.

How can I make sure anchor/fixing installations are compliant with BS 8539?

In our latest sound-out episode Stevan discusses the importance of anchor installation training.

He outlines:

• How to install an anchor in compliance with BS 8539?
• Why anchor installation training is critical for each and every anchor?
• Why it is important to use the correct setting tool for that specific anchor?

One of the most popular anchors purchased in the M&E industry, is the deformation-controlled anchor (commonly known as drop-ins). Unfortunately, the majority of them are installed incorrectly.

On-site anchor installation failure is commonly down to three issues

• The incorrect anchor has been specified and supplied on-site (find out how to correctly select an anchor BS 8539 guidance)
• The correct anchor has been specified but not supplied on-site (which can be down to a third-party influence due to breaking the spec.)
• Training - installers have not been adequately trained on how to correctly install anchors with the right setting tool

Anchor installation - BS 8539 guidance

BS 8539:2012 states that anchors should be installed and supervised by competent individuals. BS 8539 defines competent as:

“Suitably trained and qualified by knowledge and practical experience, and provided with the necessary instructions, to enable the required task(s) to be carried out correctly”.

BS 8539:2012 states that testing is not required if an ETA anchor has been used and installed and supervised by competent/trained individuals.

ETA guidance can help installers, manufacturers of anchors will put an indentation mark (often referred to as a witness mark) on the rod, this is easily visible by undoing the rod after installation - an on-site auditor will then know if a fixing has been correctly installed.

Why is anchor installation training critical for each and every anchor?

Quite simply every anchor is manufactured differently and has different installation instructions although they may look the same each anchor performs differently.

If an installer is not aware of how to correctly set an anchor or the right way to use a torque wrench then it is highly likely anchor installation failure will occur, potentially leading to on-site bracket assembly collapse. Resulting in missed project deadlines, project costs rising, and potential harm to individuals on-site. As well as the quantifiable costs, ultimately anchor installation failure can also lead to loss of earnings for the subcontractor due to a damaged brand reputation.

Minimise the risk of anchor installation failure by training the installer and the supervisor.

Why it is important to use the correct setting tool for that specific anchor?

Every anchor has a recommended setting tool ensuring an anchor can be set correctly. If you do not use the correct setting tool as outlined in the anchors’ manufacturing guidelines then it could lead to anchor installation failure.

As an example, from a manufacturer’s point of view, if there is an anchor installation failure on site and you have not used a torque wrench, typically used to install throughbolts, then you have not installed the fixing under the manufacturer's guidelines. Therefore, the installation is not compliant with BS 8539 standards.

The majority of anchor installation failures occur due to an installer not choosing the right as outlined in the manufacturer's instructions or simply not knowing how to use one correctly.

Toolbox Talk

To ensure wedge anchors are correctly set use only the setting tools supplied by the manufacturer. Using an SDS setting tool generally achieves better results than can be achieved by hand especially in overhead situations.

Every make and size of an anchor has a specific setting tool to use to ensure compliant installation.

Overall, understanding how to correctly install an anchor takes time and if not done correctly can lead to costly consequences.

A brighter future

There is a growing desire throughout the entire supply chain to reduce the risk of site failures by providing necessary training. From apprenticeship schemes to CPD's and training qualifications, the sector understands the need to upskill its workforce. Anchors and fixings must be forgotten going forward. Quite simply, without the necessary guidance and training anchors/fixings will continue to cause site failures.

Anchor/fixing compliance doesn't have to be difficult, there is guidance available, if followed can help to reduce the risk of potentially fatal site failures. We have put together an informative guide to BS 8539 fixing installation.

Start the conversation around anchor/fixing compliance.
